American Seal Supply Company |
|
Sealing Service with Integrity |
|
HYDRAULIC ACCESSORIES |
|
SPECIFICATIONS |
|
PRESSURE GAUGES |
|
¨ Copper alloy bourdon tube ¨ Dual scales ¨ Built in relief valve ¨ Acrylic lens ¨ Accuracy = 1.5% of full scale ¨ Built in snubber protects the gauge from pressure spikes ¨ Operating temperature Ambient –4° F to +140° F (-20° to +80° C) Media 150° F Max (+60° C) |
|
*1/4” NPT |
|
Part Number |
Bolt |
Description |
List Price |
Buy |
|
STF-SNA076BS-10 |
M10 |
3” Long without thermometer |
$ 14.16 |
|
|
STF-SNA076BST-10 |
M10 |
3” Long with thermometer |
17.28 |
|
|
STF-SNA127BS-12 |
M12 |
5” Long without thermometer |
18.06 |
|
|
STF-SNA127BST-12 |
M12 |
5” Long with thermometer |
20.96 |
|
FILLER BREATHER CAP |
|
¨ Chrome Plated Metal Cap ¨ 30 Mesh Metal Basket ¨ Cork Gasket ¨ Air Flow up to 25 CFM ¨ Weather Proofed |
|
SPECIFICATIONS |
|
Part Number |
Description |
List Price |
Buy |
|
STF-SAF-07-25-1 |
Filter Head 25 GPM, 3/4” NPT Return Ports |
$ 20.00 |
|
|
STF-SSF-150-25-1 |
Filter Head 80 GPM, 1-1/2” NPT Return Ports |
42.00 |
|
Part Number |
Description |
List Price |
Buy |
|
STF-SF6520 |
25 GPM Filter Element 10 µm filter paper |
$ 12.00 |
|
|
STF-SF6510 |
25 GPM Filter Element 25 µm filter paper |
12.00 |
|
Part Number |
Description |
List Price |
Buy |
|
STF-SF6720 |
80 GPM Filter Element 10 µm filter paper |
$ 21.00 |
|
|
STF-SF6710 |
80 GPM Filter Element 25 µm filter paper |
21.00 |
|
SPECIFICATIONS |
|
25 PSI FILTER BY-PASS GAUGE |
|
These plugs are used to allow air to pass in and out of NPT ports on the non-pressurized end of single-acting cylinders. It has a filter media to exclude contaminates from entering the cylinder. Click on listing for sizes. |
|
FILTER VENT PLUGS |
|
These SAE Boss O-ring plugs are used to plug SAE ports of fluid power components. Click on listing for sizes. |
|
STEEL PLUGS SAE BOSS |
|
These plugs are used to plug pipe ports of fluid power components. Click on listing for sizes. |
|
STEEL PLUGS NPT |
|
These plugs are used to allow air to pass in and out of NPT ports on the non-pressurized end of single-acting cylinders. It has a filter media to exclude contaminates from entering the cylinder. Click on listing for sizes. |
|
NPT AIR VENT |
|
Part Number |
Size |
Description |
List Price |
Buy |
|
STF-SPG-63-3030S |
2.5” |
30” HG– 30 PSI Bottom Mount |
$ 22.19 |
|
|
STF-SPG-63-100S |
2.5” |
100 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-160S |
2.5” |
160 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-500S |
2.5” |
500 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-600S |
2.5” |
600 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-1000S |
2.5” |
1,000 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-1500S |
2.5” |
1,500 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-2000S |
2.5” |
2,000 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-3000S |
2.5” |
3,000 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-5000S |
2.5” |
5,000 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-6000S |
2.5” |
6,000 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-10000S |
2.5” |
10,000 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-3000P-U* |
2.5” |
3,000 PSI Panel Mount |
22.19 |
|
|
STF-SPG-63-300S |
2.5” |
300 PSI Bottom Mount |
22.19 |
|
|
STF-SPG-63-5000P-U |
2.5” |
5,000 PSI Bottom Mount |
26.64 |
|
|
STF-SPG-100-10000S |
4” |
10,000 PSI Bottom Mount |
79.43 |
|
Part Number |
Description |
List Price |
Buy |
|
STF-SES6-P-40-N06 |
Weather Proofed Mini 40 µm 3/8” NPT |
$ 10.59 |
|
|
STF-SES3-P-40-S80 |
Weather Proofed 40µm 80mm Lng Bskt |
12.49 |
|
|
STF-SES3-40-S80 |
Filler Breather 40 µm 80mm Lng Basket |
12.04 |
|
|
STF-SES3L-40-S80 |
Locking Tab 40 µm 80mm Long Basket |
17.84 |
|
|
STF-SES3-40-S150 |
Filler Breather 40µm 150mm Lng Basket |
14.27 |
|
|
STF-SES6-40-N04 |
Filler Breather Mini 40 µm 1/4” NPT |
8.25 |
|
|
STF-SES6-40-N06 |
Filler Breather Mini 40 µm 3/8” NPT |
8.25 |
|
|
STF-SES5-40-N12 |
Filler Breather 40 µm 3/4” NPT |
11.37 |
|
|
